VgoSpringBone

VgoSpringBone is a processing-optimized Spring Bone used in Unity.

---

Features

• The processing speed and processing load are optimized.
• You can visually check the movement of the spring bone and collider with Gizmo.

Components

• VgoSpringBoneGroup
• VgoSpringBoneColliderGroup

Settings

This section explains how to set spring.

1. Spring Bone Manager

Prepare any game object. (Here we name the GameObject SpringBoneManager.)

Attach a new Vgo Spring Bone Group component to SpringBoneManager.
(If you use multiple groups, attach more components.)

2. Spring Bone

Vgo Spring Bone Group

No	item	description	required	select value	default value
1	Comment	A name to identify this group as a user.	option
2	Drag Force	The larger the value, the less likely it is to swing.	required	[0.0 - 1.0]	0.2
3	Stiffness Force	The higher the value, the easier it is to return to the original state.	required	[0.0 - 4.0]	1.0
4	Gravity Direction	The direction of gravity.	required		x: 0.0, y: -1.0, z: 0.0
5	Gravity Power	The magnitude of gravity.	required	[0.0 - 2.0]	0.2
6	Root Bones	Specify the game object at the base of the bone you want to swing. By specifying multiple root bones, the settings can be grouped together.	required
7	Hit Radius	The radius of the sphere that determines the collision of each bone.	required	[0.0 - 0.5]	0.02
8	Collider Groups	This is a group of colliders detected by this spring bone group.	option
9	Draw Gizmo	The Editor draws the Spring Bone when it draws the Gizmo.	required	true / false	false
10	Gizmo Color	The drawing color of Spring Bone.	required		yellow

If necessary, make additional settings for SpringBoneCollider.

3. Spring Bone Collider

Select the GameObject where you want to place the collider.
(For hair, head, etc.)

Attach a new Vgo Spring Bone Collider Group component to the GameObject.

Vgo Spring Bone Collider Group

No	item	description	required	select value	default value
1	Colliders	Set the spring bone collider.	required
2	Gizmo Color	The drawing color of the spring bone collider.	required		magenta

Vgo Spring Bone Collider

No	item	description	required	select value	default value
1	Collider Type	The type of collider.	required	Sphere	Sphere
2	Offset	Relative to the GameObject.	required		x: 0.0, y: 0.0, z: 0.0
3	Radius	The radius of the sphere.	required	[0.0 - 1.0]	0.0

---
