TableSO: Your All-in-One Data Management Tool 🛠️

English | 한국어

TableSO is a powerful tool for Unity that automatically generates and manages structured data and tables based on ScriptableObject and Addressables. It efficiently handles .csv files, assets within folders, and custom tables that reference other data, helping you streamline your game data management.

🧐 Dependencies

TableSO relies on the following Unity packages to seamlessly handle assets and CSVs:

• Addressables: Essential for resolving and managing CSV data and assets.
  • Don't worry if you're unfamiliar with Addressables. The entire process is automated and operates outside the user's focus.
• Unity Test Framework: Used to verify that TableSO's core features function correctly across various environments.
  • End-users do not need to run these tests; they are utilized only during the package development phase.

---

✨ Key Advantages

• Extensible ScriptableObject: Add utility methods like GetRandomItem() or GetItemListByType(type) directly to your SO, not just raw data.
• Decoupled Table and Data: Changes to data in the CSV can be updated using the UpdateData button without affecting the existing table structure. Assets use Addressable Groups, maintaining structural integrity.
• Automatic Asset Registration: Simply add assets to a designated folder, and they are automatically registered as Addressable assets.
• Seamless Updates: Use the Update Csv feature to modify data in .csv files without altering the table structure or methods.
• Persistent Data: Once data is loaded, it remains available even when scenes change, eliminating the need for repeated loading.
• High Performance: Provides fast lookup times through efficient Dictionary caching.

---

Download and Setup

1. In the Unity Editor's top bar, navigate to Window > Package Manager.
2. Click the + button in the upper-left corner and select Add package from git URL....
3. Enter the following URL and install the package:

   https://github.com/jadestar01/TableSO.git?path=Packages/com.jadestar01.tableso#v1.0.5


4. Run the TableEditor by clicking the TableSO tab in the Unity top menu.
5. In the Editor's Center tab, click Create TableCenter to finalize the directory structure and Addressable settings, creating the central TableCenter asset.

🗺️ How it Works

1. TableEditor

The TableEditor is the central hub for managing all your tables. It can be opened via:

• Keyboard Shortcut: [CTRL + T] on Windows, [CMD + T] on Mac.
• Menu Tab: Through the [TableSO] tab in the Unity Editor's main menu.

2. TableCenter

The TableCenter acts as the central repository, managing references to all tables. You can easily retrieve a specific table using the generic method GetTable<T>.

• Initialize(): It is required to refresh the data of all tables. Through this method, the data can be read.
• OnInitialized: An event that can be used to register methods to perform specific actions—such as scene transitions—after data loading is complete.

using TableSO.Scripts;
using Table;

public class TableLoader : MonoBehaviour
{
    public TableCenter center;

    private void Awake()
    {
        center.OnInitialized += AfterInitialize;
        center.Initialize();
    }

    private void AfterInitialize()
    {
        Debug.Log("Init Complete");
        var table = center.GetTable<DamageExpressionDataTableSO>();
    }
}

---

📂 Table Types

TableSO supports three distinct table types to satisfy all your data requirements.

1. CsvTable

• Structure: A [TKey, TData] table that reads from a .csv file. It resolves TKey and generates TData based on the file content.
• CSV Rules:
  • First Row: Must contain variable names. (Follow standard variable naming conventions.)
  • Second Row: Must contain variable types. (enum and array types are supported.)
  • First column: The variable name must be ID. (Must Unique)
  • Arrays: Elements are separated using the pipe character | (e.g., 1|2|3).
• A DataClass is generated based on each row, and a TableClass is generated based on the ID.

2. AssetTable

• Structure: A [string, TData] table that reads data from a designated folder. It uses the file name (string) as the TKey and generates TData.
• You can filter and specify the asset types to be read.
• All assets are stored as Addressables and are loaded automatically at game start.
• Supported Asset Filters: Sprite, Prefab, ScriptableObject, Texture2D, AudioClip, AnimationClip, Material, TextAsset

3. CustomTable

• Structure: A [TKey, TData] table that generates complex data by referencing other tables (CsvTable, AssetTable, etc.).
• You must select the related tables to link before creation.
• The user must define TData directly (constructor and field definitions) and implement the logic within the UpdateData() method to read data from the linked tables and build the final data list.

---

👩‍💻 Usage Example: Item Management

Let's assume you want to create an item system by combining item sprites and item information. Here's how to use TableSO:

1. Create an AssetTable for ItemSprite: Use the Sprite filter to include all item sprites from a folder.
2. Create a CsvTable for ItemData: This table holds all item information, including the sprite name as a variable.
3. Create a CustomTable for Item: This will be the final, integrated item class.
4. Refresh All Tables: Go to the Center tab of the TableEditor and click RefreshAllTable to generate ScriptableObjects and resolve references.
5. Define Classes: Define ItemData and ItemSprite fields in the automatically generated Item class and set up the constructor.
6. Implement Update Logic: Implement the UpdateData logic in ItemCustomTable to use data from ItemSpriteAssetTable and ItemDataCsvTable to construct the final Item objects.
7. Access in Script: Reference the tableCenter in your ItemManager (or other script).
8. Get the Table: Use tableCenter.GetTable<ItemCustomTable>() to retrieve the merged item table.
9. Search Data: Access all item keys using GetAllKey(), and retrieve a specific Item object using GetData(key).

---

Scenario: Displaying Data and Assets in UI

This scenario demonstrates combining CSV data and assets using a Custom Table for UI display.

1. Create a Data Table (CsvTable)

1. Create a file named ExampleData.csv in the automatically generated path: Assets/TableSO/Data.
   • The first row must be element names, and the second row must be element types.
   • Array types are separated by the | character. Enums are tracked automatically.
2. Open the TableSOEditor, navigate to the Csv tab, select ExampleData.csv via Browse, and click the button to generate the code.
3. Go to the Center tab and click Refresh All Tables to register the Table with the Center.
   • ExampleData.csv is now available as a referenceable object in Unity.

ID	IconName	Text
int	string[]	string
1	T	Hello
2	T|A	World
3	T|A|B	TableSO
4	T|A|B|L	Is
5	T|A|B|L|E	Fun
6	T|A|B|L|E|S	And
7	T|A|B|L|E|S|O	Easy

This table references Icon Sprite Asset file names in the IconName array.

2. Create an Asset Table (AssetTable)

1. Create a folder named ExampleIcon and place your desired assets (e.g., Sprite assets) in the automatically generated path: Assets/TableSO/Asset.
2. Open the TableSOEditor, navigate to the Asset tab, select the ExampleIcon folder via Browse, choose the Type (e.g., Sprite), and generate the code.
3. Go to the Center tab and click Refresh All Tables to register the Table with the Center.
   • All assets of the selected type within the ExampleIcon folder are now referenceable in Unity.

3. Create a Custom Table (CustomTable)

The CSV data references assets, so we combine them using a Custom Table for easy access.

1. Open the TableSOEditor and navigate to the Custom tab.
2. Select ExampleDataTableSO and ExampleIconAssetTableSO as the tables to link.
3. Enter the final class name (e.g., Example) in the Table Name field.
4. Select the Key Type, which should be the same as the data key type (e.g., int), as ExampleData is keyed by int.
5. Click Refresh All Tables again to resolve references.
6. You must now manually define the generated data class Example and the table class ExampleTableSO to define the connection logic.

Example.cs (Data Class Definition)

namespace TableData
{
    using System.Collections.Generic;
    using UnityEngine;

    [System.Serializable]
    public class Example : IIdentifiable<int>
    {
        [field: SerializeField] public int ID { get; internal set; }

        public List<Sprite> Icons = new List<Sprite>();

        public string Text;

        public Example(int ID, List<Sprite> Icons, string Text)
        {
            this.ID = ID;
            this.Icons = Icons;
            this.Text = Text;
        }
    }
}

ExampleTableSO.cs (Update Logic Implementation)

namespace Table
{
    using TableData;
    using System;
    using System.Collections.Generic;
    using System.Threading.Tasks;
    using UnityEngine;
    using TableSO.Scripts;

    public class ExampleTableSO : CustomTableSO<int, Example>
    {
        public override TableType tableType => TableType.Custom;

        public string fileName => "ExampleTableSO";
        [SerializeField] private ExampleDataTableSO ExampleDataTable;
        [SerializeField] private ExampleIconAssetTableSO ExampleIconAssetTable;

        public override List<Type> refTableTypes { get; set; } = new List<Type>()
        {
            typeof(ExampleDataTableSO),
            typeof(ExampleIconAssetTableSO),
        };

        public override async Task UpdateData()
        {
            ReleaseData(); // Clear old data

            foreach (var id in ExampleDataTable.GetAllKey())
            {
                List<Sprite> icons = new List<Sprite>();

                // Use the IconName (string array from CsvTable) to retrieve Sprite assets from the AssetTable.
                foreach (var iconName in ExampleDataTable.GetData(id).IconName)
                    icons.Add(ExampleIconAssetTable.GetData(iconName).Asset);

                // Construct the final Example object and add it to the dataList.
                dataList.Add(new Example(id, icons, ExampleDataTable.GetData(id).Text));
            }

            base.UpdateData(); // Finalize caching
        }

        public override Example GetData(int key)
        {
            // The base implementation provides dictionary lookup. Override for custom logic.
            return base.GetData(key);
        }
    }
}

4. Runtime Access

The final data can be accessed in your code as follows:

// Assume tableCenter is referenced in your script
    var table = tableCenter.GetTable<ExampleTableSO>();
    var data = table.GetData(id); // Retrieve the integrated Example object by ID

    foreach (var icon in data.Icons)
    {
        Image image = GetImage(); // Example function to get a UI Image component
        image.sprite = icon;
    }

    text.text = data.Text;
