Pulse

Table of Contents

• Getting Started
  • Prerequisites
  • Manual Installation
  • UPM Installation
• Features
• Usage
  • Define your systems
  • Declare dependencies via attributes
  • Build an initialization context
  • Tuning dependencies manually
  • Listening to per-system callbacks
• API Reference
  • IInitializable
  • InitDependencyAttribute
  • InitializationContextBuilder
  • InitializationContext
  • IInitializationNodeHandle
• Dependencies
• License

Getting Started

Prerequisites

• GIT
• Unity 2022.3+

Manual Installation

1. Download the .unitypackage from the releases page.
2. Import com.dtech.pulse.x.x.x.unitypackage into your project.

UPM Installation

1. Open the manifest.json file in your project's Packages folder.
2. Add the following line to the dependencies section:

   "com.dtech.pulse": "https://github.com/DanilChizhikov/pulse.git",


3. Unity will automatically import the package.

If you want to set a target version, Logging uses the v*.*.* release tag so you can specify a version like #v1.0.0.

For example https://github.com/DanilChizhikov/pulse.git#v1.0.0.

Features

• Attribute–based dependency discovery

  System automatically discovers dependencies between systems using the InitDependencyAttribute on:

  • fields,
  • properties,
  • methods parameters,
  • constructors. It then builds a dependency graph and orders initialization accordingly.

• Deterministic, batched initialization

  Systems are initialized in topological order, grouped into batches. All systems in the same batch are initialized in parallel (as Tasks), and the next batch starts only after the current one is done.

• Strong validation of dependencies During Build() Initialization:

  • verifies that every declared dependency has a corresponding system registered via AddSystem;
  • detects cyclic dependencies and fails fast with a clear error.

  This prevents situations where initialization silently “hangs” due to unresolved or circular dependencies.

• Manual fine‑tuning of dependencies

  For each added system you can:

  • add dependencies manually (AddDependency, AddDependencies);
  • remove or override automatically discovered dependencies (RemoveDependency, RemoveDependencies).

  This lets you adjust the dependency graph without changing the system’s implementation.

• Critical systems support

  You can mark systems as critical.

  The InitializationContext tracks them and raises OnCriticalSystemsInitialized once all critical systems are successfully initialized.

• Initialization callbacks per system

  For each system you can subscribe to:

  • OnStartInitialize — called when initialization of a specific system starts;
  • OnCompleteInitialize — called when initialization of a specific system finishes.

  This is useful for logging, profiling, or progress reporting.

• Cancellation support

  InitializationContext.InitializationAsync takes a CancellationToken.

  If the token is canceled:

  • Pulse stops processing further batches;
  • any already running tasks can respect the token and exit early.

Usage

Define your systems

Each system must implement IInitializable:

using System.Threading;
using System.Threading.Tasks;
using DTech.Pulse;

public sealed class DatabaseSystem : IInitializable
{
    public Task InitializeAsync(CancellationToken token)
    {
        // Connect to DB, run migrations, etc.
        return Task.CompletedTask;
    }
}

public sealed class AuthSystem : IInitializable
{
    private readonly DatabaseSystem _database;

    public AuthSystem(DatabaseSystem database)
    {
        _database = database;
    }

    public Task InitializeAsync(CancellationToken token)
    {
        // Initialize auth flow, cache, etc.
        return Task.CompletedTask;
    }
}

Declare dependencies via attributes

You can mark dependencies so Pulse can discover them automatically:

using DTech.Pulse;

public sealed class GameplaySystem : IInitializable
{
    [InitDependency]
    private AuthSystem _authSystem;

    public Task InitializeAsync(CancellationToken token)
    {
        // Game logic that requires auth.
        return Task.CompletedTask;
    }
}

You can also place InitDependency on:

• properties:

  [InitDependency]
  private DatabaseSystem Database { get; set; }


• methods (on parameters):

  [InitDependency]
  private void Setup(AuthSystem auth, GameplaySystem gameplay) { }


• constructors (or select a constructor with InitDependency if there are multiple):

  public sealed class AnalyticsSystem : IInitializable
  {
      private readonly DatabaseSystem _database;

      [InitDependency]
      pulic AnalyticsSystem(DatabaseSystem database)
      {
          _database = database;
      }

      pulic AnalyticsSystem(DatabaseSystem database, AuthSystem auth)
      {
          _database = database;
      }

      public Task InitializeAsync(CancellationToken token) => Task.CompletedTask;
  }


  All collected dependency types are filtered to only those implementing IInitializable.

Build an initialization context

In your bootstrap code (e.g. in a Unity entry point):

using System.Threading;
using DTech.Pulse;

public sealed class GameBootstrap
{
    private InitializationContext _context;

    public void Setup()
    {
        var builder = new InitializationContextBuilder();

        var db = new DatabaseSystem();
        var auth = new AuthSystem(db);
        var gameplay = new GameplaySystem();
        var analytics = new AnalyticsSystem(db);

        builder.AddSystem(db).SetAsCritical();            // DB as critical
        builder.AddSystem(auth);                        // depends on DB via ctor
        builder.AddSystem(gameplay);                    // depends on Auth via [InitDependency]
        builder.AddSystem(analytics);                   // depends on DB via [InitDependency] ctor

        _context = builder.Build();
    }

    public async Task InitializeAsync(CancellationToken token)
    {
        // Optional: react when all critical systems are ready
        _context.OnCriticalSystemsInitialized += () =>
        {
            // e.g. show main menu
        };

        await _context.InitializationAsync(token);
    }
}

Tuning dependencies manually

You can add or remove dependencies programmatically, on top of what attributes determined

var builder = new InitializationContextBuilder();

var db = new DatabaseSystem();
var auth = new AuthSystem(db);

// Add systems
IInitializationNodeHandle dbNode   = builder.AddSystem(db);
IInitializationNodeHandle authNode = builder.AddSystem(auth);

// Add an extra dependency explicitly
authNode.AddDependency<DatabaseSystem>();

// Remove all dependencies that are assignable to some base type:
authNode.RemoveDependencies(typeof(IInitializable)); // example: aggressively remove

If you accidentally reference a dependency that was not added to the builder, Build() will throw an exception:

var builder = new InitializationContextBuilder();
builder.AddSystem(auth).AddDependency<DatabaseSystem>(); // DatabaseSystem not added

// Throws:
var context = builder.Build();

Listening to per-system callbacks

You can attach callbacks to know when a specific system starts or completes initialization:

builder.AddSystem(db)
       .OnStartInitialize(type => Debug.Log($"Start init: {type.Name}"))
       .OnCompleteInitialize(type => Debug.Log($"Complete init: {type.Name}"));

API Reference

This section covers the main public types. Internal types are not part of the public API and may change.

IInitializable

public interface IInitializable
{
  Task InitializeAsync(CancellationToken token);
}

Interface that all systems must implement.

Task InitializeAsync(CancellationToken token)

Called by Pulse during the initialization pass.

• Use token to support cancellation (e.g. abort long-running operations).
• May perform async work (network calls, I/O, loading, etc).

InitDependencyAttribute

[AttributeUsage(AttributeTargets.Field | AttributeTargets.Property | AttributeTargets.Method | AttributeTargets.Constructor)]
public sealed class InitDependencyAttribute : Attribute
{
}

Marks a member that declares dependencies of the system:

• Fields / Properties: the member type is treated as a dependency.
• Methods: all parameter types are treated as dependencies.
• Constructors: all parameter types are treated as dependencies. If multiple constructors exist:
  • The one with InitDependencyAttribute is preferred;
  • Otherwise, the first public constructor is used.

Only types that implement IInitializable are kept as dependencies.

Example:

public sealed class InventorySystem : IInitializable
{
    [InitDependency]
    private GameplaySystem _gameplay;

    [InitDependency]
    private void Setup(AuthSystem auth, DatabaseSystem db) { }

    public Task InitializeAsync(CancellationToken token) => Task.CompletedTask;
}

InitializationContextBuilder

public sealed class InitializationContextBuilder
{
    public IInitializationNodeHandle AddSystem(IInitializable system);
    public InitializationContext Build();
}

Responsible for registering systems and building the initialization plan.

AddSystem(IInitializable system)

Registers a system for initialization and returns an IInitializationNodeHandle to configure it.

• Automatically discovers dependencies using InitDependencyAttribute and constructors.
• Throws if a system with the same runtime type has already been added (depending on your current version; if not present you can easily add this check).

Example:

var builder = new InitializationContextBuilder();

var db = new DatabaseSystem();
var auth = new AuthSystem(db);

builder.AddSystem(db)
       .SetAsCritical();

builder.AddSystem(auth)
       .OnStartInitialize(type => Console.WriteLine($"Init {type.Name}..."));

Build()

Builds the dependency graph, creates batches, and returns an InitializationContext. Validation performed during Build():

• Missing dependencies: if any system depends on a type that has no matching system registered, Build() throws an exception.
• Cyclic dependencies: if a cycle is detected, Build() throws an exception with the list of involved systems.

InitializationContext

public sealed class InitializationContext
{
    public event Action OnCriticalSystemsInitialized;

    public Task InitializationAsync(CancellationToken token);
}

Represents a compiled initialization plan.

OnSystemInitializationBegan

Event fired when a system begins initialization system.

Example:

context.OnSystemInitializationBegan += type =>
{
    Debug.Log($"Init {type.Name}...");
};

OnSystemInitializationComplete

Event fired when a system complete initialization.

Example:

context.OnSystemInitializationComplete += type =>
{
    Debug.Log($"Init {type.Name}...");
};

OnCriticalSystemsInitialized

Event fired once all critical systems (marked via SetAsCritical()) have completed initialization.

Example:

context.OnCriticalSystemsInitialized += () =>
{
    Debug.Log("All critical systems are ready!");
};

InitializationAsync(CancellationToken token)

Runs initialization:

• Systems are executed in batches according to their dependencies.
• Systems within the same batch are initialized in parallel using Task.WhenAll.
• If token is canceled:
  • The method returns early after the current batch is done.
  • Remaining batches are not processed.

Example:

var cts = new CancellationTokenSource();

try
{
    await context.InitializationAsync(cts.Token);
}
catch (OperationCanceledException)
{
    // Handle cancellation if your systems throw it.
}

IInitializationNodeHandle

public interface IInitializationNodeHandle
{
    Type SystemType { get; }

    IInitializationNodeHandle AddDependency<T>() where T : IInitializable;
    IInitializationNodeHandle AddDependencies(params Type[] dependencies);

    IInitializationNodeHandle RemoveDependency<T>() where T : IInitializable;
    IInitializationNodeHandle RemoveDependencies(params Type[] dependencies);

    IInitializationNodeHandle SetAsCritical();

    IInitializationNodeHandle OnStartInitialize(Action<Type> callback);
    IInitializationNodeHandle OnCompleteInitialize(Action<Type> callback);
}

Fluent configuration interface returned by AddSystem.

SystemType

The runtime type of the registered system.

AddDependency() / AddDependencies(params Type[] types)

Adds explicit dependencies.

All types must implement IInitializable, otherwise an exception is thrown. Example:

builder.AddSystem(gameplay)
       .AddDependency<AuthSystem>();

RemoveDependency() / RemoveDependencies(params Type[] types)

Removes dependencies that were previously added or discovered.

• Removal uses IsAssignableFrom, so passing a base type removes all compatible dependencies.

Example:

// Remove a specific dependency
node.RemoveDependency<AuthSystem>();

// Remove all dependencies implementing some base interface
node.RemoveDependencies(typeof(IMySubsystemBase));

SetAsCritical()

Marks this system as critical. The InitializationContext will track it and only raise OnCriticalSystemsInitialized once all critical systems are done.

builder.AddSystem(db).SetAsCritical();

OnStartInitialize(Action callback) / OnCompleteInitialize(Action callback)

Registers callbacks for a particular system:

builder.AddSystem(db)
       .OnStartInitialize(type => Debug.Log($"Start: {type.Name}"))
       .OnCompleteInitialize(type => Debug.Log($"Done: {type.Name}"));

If you want, I can also add a small “Quick Start” snippet above these sections showing a full minimal example from builder setup to initialization call.

Dependencies

• Performance Testing Package for Unity v3.2.0

License

This project is licensed under the MIT License. See the LICENSE file for details.
