WebSocketConnection

WebSocketConnection is an ergonomic, idiomatic websocket client for Unity. Write-once for all platforms, including Web.

• Ergonomics
  • Does not force you to use async
  • Does not force you to use #if conditional compilation
  • Listen for messages however you want: events, coroutines, polling, or async/await
• Reliability
  • Reusable: connect, disconnect, change URL, connect, ...
  • string is sent as text type, byte[] as binary type
  • Proper handling of disconnects and bad messages
  • Tested with 100+ WebSocketConnection components with minimal drop in framerate
• Extended Features
  • Custom ping-pongs which can be configured to calculate ping times. ℹ️ You must control the server for this.
  • Self-signed certificate support. ⚠️ Non-Web only, must use .NET Framework Api level.

Why Use This?

WebSocketConnection has the most ergonomic, write-once support across platforms:

Supports	WebSocketConnection	NativeWebSocket	System.Net.WebSockets.ClientWebSocket
WebGL	✅	✅	⛔️
WebAssembly.Table	✅	✅	⛔️
Requires using async	✅ Optional	⚠️ Required	⚠️ Required
Code changes for WebGL	✅ None	✅ None	⛔️ Need custom jslib
Self-signed certs	✅ non-Web	⛔️	✅ non-Web
Write-once ping-pong	✅	⛔️	⛔️

Installation

See official instructions for how to Install a Package from a Git URL. The URL is

https://github.com/mikerochip/unity-websocket.git

Known Limitations

• Self-Signed Certs
  • Only works in editor and non-web builds
  • Required Api Compatibility Level .NET Framework
  • Requires lots of fiddly setup, see sample below
• Web Limitations
  • The underlying Web implementation uses the default browser JavaScript WebSocket API to minimize depedencies, which has limitations
  • No custom header support. See this
  • No self-signed certs support
  • No spec-compliant ping-pong support. ℹ️ Use the custom ping-pong feature instead, which also adds ping timing support.

Test Projects

For reference, if you don't want to roll your own:

• Server test project
• Client test project

Samples

Assume we have a class like this for the following samples:

using MikeSchweitzer.WebSocket;

public class Tester : MonoBehaviour
{
    public WebSocketConnection _Connection;
    public string _Url = "wss://ws.postman-echo.com/raw";
}

Connect

// inline style
public void Connect()
{
    _Connection.Connect(_Url);
}

// property style
public void Connect()
{
    _Connection.DesiredConfig = new WebSocketConfig
    {
        Url = _Url,
    };
    _Connection.Connect();
}

Disconnect

public void Disconnect()
{
    _Connection.Disconnect();
}

State Querying

Update Style

private WebSocketState _oldState;

private void Update()
{
    var newState = WebSocketConnection.State;
    if (_oldState != newState)
    {
        Debug.Log($"OnStateChanged oldState={_oldState}|newState={newState}");
        _oldState = newState;
    }
}

Event Style

private void Awake()
{
    _Connection.StateChanged += OnStateChanged
}

private void OnDestroy()
{
    _Connection.StateChanged -= OnStateChanged;
}

private void OnStateChanged(WebSocketConnection connection, WebSocketState oldState, WebSocketState newState)
{
    Debug.Log($"OnStateChanged oldState={oldState}|newState={newState}");
}

Reconnect

Coroutine Style

public IEnumerator Reconnect()
{
    Disconnect();
    yield return new WaitUntil(_Connection.State == WebSocketState.Disconnected);

    // you may change the url here, if you want
    Connect();
}

Event Style

private void OnStateChanged(WebSocketConnection connection, WebSocketState oldState, WebSocketState newState)
{
    if (newState == WebSocketState.Disconnected)
    {
        // you may change the url here, if you want
        _Connection.Connect();
    }
}

Error Messages

[!NOTE] These are just error messages, not states. See the State Querying section.

Error messages are generally derived from platform-specific WebSocket errors.

private void Awake()
{
    _Connection.ErrorMessageReceived += OnErrorMessageReceived;
}

private void OnDestroy()
{
    _Connection.ErrorMessageReceived -= OnErrorMessageReceived;
}

private void OnErrorMessageReceived(WebSocketConnection connection, string errorMessage)
{
    // you can also use _Connection.ErrorMessage
    Debug.LogError(errorMessage);
}

Send Messages

[!WARNING] You must be Connected to send messages, otherwise you will get an error

public void SendString()
{
    _Connection.AddOutgoingMessage("hello");
}

public void SendBinary()
{
    var bytes = Encoding.UTF8.GetBytes("hello");
    _Connection.AddOutgoingMessage(bytes);
}

Receive Messages

Update Style

private void Update()
{
    while (_Connection.TryRemoveIncomingMessage(out string message))
        Debug.Log(message);
}

Event Style

private void Awake()
{
    _Connection.MessageReceived += OnMessageReceived;
}

private void OnDestroy()
{
    _Connection.MessageReceived -= OnMessageReceived;
}

private void OnMessageReceived(WebSocketConnection connection, WebSocketMessage message)
{
    Debug.Log(message.String);
}

Coroutine Style

private void Awake()
{
    StartCoroutine(ReceiveMessages());
}

private IEnumerator ReceiveMessages()
{
    while (true)
    {
        if (_Connection.TryRemoveIncomingMessage(out string message))
            Debug.Log(message);
        yield return null;
    }
}

Async/Await Style

private CancellationTokenSource _cts;

private async void Awake()
{
    _cts = new CancellationTokenSource();
    await ReceiveMessagesAsync();
}

private void OnDestroy()
{
    _cts.Cancel();
}

private async Task ReceiveMessagesAsync()
{
    while (!_cts.IsCancellationRequested)
    {
        if (_Connection.TryRemoveIncomingMessage(out string message))
            Debug.Log(message);

        await Task.Yield();
    }
}

Custom Ping-Pong Support

This package has a custom ping-pong feature that you can write once for Web and non-Web builds.

[!WARNING]

• Your server must be configured to echo messages of the same message type (text or binary) and content.
• This package has custom ping-pong support because the default browser JavaScript WebSocket client does not implement the WebSocket Ping Pong spec even though .NET's WebSocketClient does implement the spec.

Enable Text Ping-Pongs

private void ConfigureStringPings()
{
    _Connection.DesiredConfig = new WebSocketConfig
    {
        Url = _Url,
        PingInterval = TimeSpan.FromSeconds(30),
        PingMessage = new WebSocketMessage("hi"),
    };
}

Enable Binary Ping-Pongs

private byte[] _pingBytes = Encoding.UTF8.GetBytes("hi");
private void ConfigureBinaryPings()
{
    _Connection.DesiredConfig = new WebSocketConfig
    {
        Url = _Url,
        PingInterval = TimeSpan.FromSeconds(30),
        PingMessage = new WebSocketMessage(_pingBytes),
    };
}

Ping Timing (Round-Trip-Time Tracking)

private void Awake()
{
    _Connection.DesiredConfig = new WebSocketConfig
    {
        Url = _Url,
        PingInterval = TimeSpan.FromSeconds(3),
        PingMessage = new WebSocketMessage("hi"),
        ShouldPingWaitForPong = true,
    };
    _Connection.PingSent += OnPingSent;
    _Connection.PongReceived += OnPongReceived;
}

private void OnDestroy()
{
    _Connection.PingSent -= OnPingSent;
    _Connection.PongReceived -= OnPongReceived;
}

private void OnPingSent(WebSocketConnection connection, DateTime timestamp)
{
    Debug.Log($"OnPingSent timestamp={timestamp:HH:mm:ss.ffff}");
}

private void OnPongReceived(WebSocketConnection connection, DateTime timestamp)
{
    Debug.Log($"OnPongReceived timestamp={timestamp:HH:mm:ss.ffff}");
    Debug.Log($"OnPongReceived RTT={connection.LastPingPongInterval:ss\\.ffff}");
}

Self-Signed Certificates

If you must use self-signed certificates, then there is a way to make that work with this package by following roughly these steps.

[!WARNING] I highly recommend against self-signed certs. These steps are easy to mess up and overly complicated.

I highly recommend instead:

• Trusted CA certs
• CA certs pre-installed on your servers and devices
• Just using insecure ws:

1. Create a certificate with e.g. openssl
   • Example: openssl req -x509 -newkey rsa:2048 -nodes -out cert.pem -keyout key.pem -days 365 -subj "/CN=example.local" -addext "subjectAltName=DNS:localhost,IP:127.0.0.1,DNS:my-example-domain.com"
   • In the above example, replace my-example-domain.com with your domain name (if you have one, otherwise leave out the DNS: SAN)
2. Export a pfx file from your cert
   • Example: openssl pkcs12 -export -in cert.pem -inkey key.pem -out cert.pfx -password pass:mypass -macalg SHA1 -certpbe PBE-SHA1-3DES -keypbe PBE-SHA1-3DES
   • In the above example, replace mypass with a password of your choosing
   • ⚠️NOTE: You MUST use these algorithm options or Unity will fail to load your cert
3. Set your Unity project's Api Compatibility Level to .NET Framework
4. Create a class like this somewhere in your project

   using System.Net;
   using System.Security.Cryptography.X509Certificates;

   private class SelfSignedCertTrustPolicy : ICertificatePolicy
   {
       public bool CheckValidationResult(ServicePoint servicePoint, X509Certificate certificate, WebRequest request, int certificateProblem)
       {
           return true;
       }
   }


5. In some Awake() method somewhere, add this line:

   ServicePointManager.CertificatePolicy = new SelfSignedCertTrustPolicy();


6. Configure your server to load the certs
   • This totally depends on your server
   • You can see an example from my test server here
7. Configure this Unity package to load the certs
   • Put your cert.pfx in your Unity project as cert.pfx.bytes
   • Do similar with the password you made earlier: put your password in a text file like cert.pfx.pass.bytes
   • Load both of those in your code as TextAsset
   • Then do MyWebSocketConfig.DotNetSelfSignedCert = MyCert.bytes
   • And MyWebSocketConfig.DotNetSelfSignedCertPassword = MyCertPassword.text.ToCharArray()

WebSocketConnection should now be able to use wss: to connect to your server.

Attribution

Based on this repo by Endel Dreyer, which was based on this repo by Jiri Hybek

See license and third party notices for full attribution.
