LogicLooper

日本語

A library is for building server application using loop-action programming model on .NET. This library focuses on building game servers with server-side logic.

For example, if you have the following game loops, the library will provide a way to aggregate and process in a more efficient way than driving with a simple Task.

while (true)
{
    // some stuff to do ...
    network.Receive();
    world.Update();
    players.Update();
    network.Send();
    // some stuff to do ...

    // wait for next frame
    await Task.Delay(16);
}

using var looper = new LogicLooper(60);
await looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    // The action will be called by looper every frame.
    // some stuff to do ...
    network.Receive();
    world.Update();
    players.Update();
    network.Send();
    // some stuff to do ...

    return true; // wait for next update
});

Table of Contents

• Installation
• Usage
  • Single-loop application
  • Multiple-loop application using LooperPool
  • Integrate with Microsoft.Extensions.Hosting
  • Metrics
• Advanced
  • Unit tests / Frame-by-Frame execution
  • Coroutine
  • TargetFrameRateOverride
• Experimental
  • async-aware loop actions

Installation

PS> Install-Package LogicLooper

$ dotnet add package LogicLooper

Usage

Single-loop application

A Looper bound one thread and begin a main-loop. You can register multiple loop actions for the Looper. It's similar to be multiple Update methods called in one frame of the game engine.

using Cysharp.Threading;

// Create a looper.
const int targetFps = 60;
using var looper = new LogicLooper(targetFps);

// Register a action to the looper and wait for completion.
await looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    // If you want to stop/complete the loop, return false to stop.
    if (...) { return false; }

    // some stuff to do ...

    return true; // wait for a next update.
});

Multiple-loop application using LooperPool

For example, if your server has many cores, it is more efficient running multiple loops. LooperPool provides multiple loopers and facade for using them.

using Cysharp.Threading;

// Create a looper pool.
// If your machine has 4-cores, the LooperPool creates 4-Looper instances.
const int targetFps = 60;
var looperCount = Environment.ProcessorCount;
using var looperPool = new LogicLooperPool(targetFps, looperCount, RoundRobinLogicLooperPoolBalancer.Instance);

// Register a action to the looper and wait for completion.
await looperPool.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    // If you want to stop/complete the loop, return false to stop.
    if (...) { return false; }

    // some stuff to do ...

    return true; // wait for a next update.
});

Integrate with Microsoft.Extensions.Hosting

See samples/LoopHostingApp.

Metrics

LogicLooper provides metrics using the Metric API. This allows you to obtain the number of LogicLoopers and registered actions, as well as the execution time per loop.

To enable metrics collection, install the LogicLooper.Diagnostics package and call AddLogicLooperMetrics.

services.AddLogicLooperMetrics();

Instrumentation	Unit	Description
LogicLooper.shared_pool.loopers	{looper}	Number of LogicLooper instances running in LogicLooperPool.Shared
LogicLooper.shared_pool.running_actions	{action}	Number of actions registered in LogicLooperPool.Shared that are running in LogicLooper
LogicLooper.running_loopers	{looper}	Number of LogicLooper instances running in the process
LogicLooper.running_actions	{action}	Number of actions registered in LogicLooper that are running in the process
LogicLooper.processing_duration_min	ms	Minimum execution time of one loop in the process for LogicLooper
LogicLooper.processing_duration_max	ms	Maximum execution time of one loop in the process for LogicLooper
LogicLooper.processing_duration_avg	ms	Average execution time of one loop in the process for LogicLooper

Advanced

Unit tests / Frame-by-Frame execution

If you want to write unit tests with LogicLooper or update frames manually, you can use ManualLogicLooper / ManualLogicLooperPool.

var looper = new ManualLogicLooper(60.0); // `ElapsedTimeFromPreviousFrame` will be fixed to `1000 / FrameTargetFrameRate`.

var count = 0;
var t1 = looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    count++;
    return count != 3;
});

looper.Tick(); // Update frame
Console.WriteLine(count); // => 1

looper.Tick(); // Update frame
Console.WriteLine(count); // => 2

looper.Tick(); // Update frame (t1 will be completed)
Console.WriteLine(count); // => 3

looper.Tick(); // Update frame (no action)
Console.WriteLine(count); // => 3

Coroutine

LogicLooper has support for the coroutine-like operation. If you are using Unity, you are familiar with the coroutine pattern.

using var looper = new LogicLooper(60);

var coroutine = default(LogicLooperCoroutine);
await looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    if (/* ... */)
    {
        // Launch a coroutine in the looper that same as the loop action.
        coroutine = ctx.RunCoroutine(async coCtx =>
        {
            // NOTE: `DelayFrame`, `DelayNextFrame`, `Delay` methods are allowed and awaitable in the coroutine.
            // If you await a Task or Task-like, the coroutine throws an exception.
            await coCtx.DelayFrame(60);

            // some stuff to do ...

            await coCtx.DelayNextFrame();

            // some stuff to do ...

            await coCtx.Delay(TimeSpan.FromMilliseconds(16.66666));
        });
    }

    if (coroutine.IsCompleted)
    {
        // When the coroutine has completed, you can do some stuff ...
    }

    return true;
});

TargetFrameRateOverride

TargetFrameRateOverride option allows to override the frame rate for each action. This can be useful in cases where you want to mix multiple frame rates, such as expecting the main loop to run at 30fps, but wanting some actions to be called at 5fps.

You can also set the frame rate for each Looper that executes the loops, but the design of LogicLooper is 1-loop per thread, so in principle we expect a number of Loopers in accordance with the number of cores. By setting the frame rate for each action, you can keep the number of Loopers fixed even if the workload changes.

using var looper = new LogicLooper(60); // 60 fps

await looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    // Something to do ...
    return true;
}); // The action will be called at 60fps.

await looper.RegisterActionAsync((in LogicLooperActionContext ctx) =>
{
    // Something to do (low priority) ...
    return true;
}, LooperActionOptions.Default with { TargetFrameRateOverride = 10 }); // The action will be called at 10fps.

The granularity of action execution changes based on the execution frequency of the main loop itself. This means that the accuracy may be inferior to the target frame rate of the Looper.

Experimental

async-aware loop actions

Experimental support for loop actions that can await asynchronous events.

With SynchronizationContext, all asynchronous continuations are executed on the loop thread. Please beware that asynchronous actions are executed across multiple frames, unlike synchronous actions.

await looper.RegisterActionAsync(static async (ctx, state) =>
{
    state.Add("1"); // Frame: 1
    await Task.Delay(250);
    state.Add("2"); // Frame: 2 or later
    return false;
});

[!WARNING] If an action completes immediately (ValueTask.IsCompleted = true), there's no performance difference from non-async version. But it is very slow if there's a need to await. This asynchronous support provides as an emergency hatch when it becomes necessary to communicate with the outside at a low frequency. We do not recommended to perform asynchronous processing at a high frequency.
