LiveKit Unity SDK

⚠️ Warning

This SDK is currently in Developer Preview mode and not ready for production use. There will be bugs and APIs may change during this period.

We welcome and appreciate any feedback or contributions. You can create issues here or chat live with us and other users in our community at https://community.livekit.io/.

Use this SDK to add realtime video, audio and data features to your Unity app. By connecting to LiveKit Cloud or a self-hosted server, you can quickly build applications such as multi-modal AI, live streaming, or video calls with just a few lines of code.

SDK Reference »

Platform Support

• Windows

• MacOS

• Linux

• iOS

• Android

• WebGL

We plan to support all Unity platforms with this SDK. WebGL is currently supported with client-sdk-unity-web.

Installation

Follow this unity tutorial,

clone this repo and download the ffi binaries.

git  clone  https://github.com/livekit/client-sdk-unity.git

cd  client-sdk-unity

You can use the package manager to import local client-sdk-unity into your Unity project.

Or you can import the git url https://github.com/livekit/client-sdk-unity.git from the package manager. If you want to use tagged release versions, use https://github.com/livekit/client-sdk-unity.git#vX.X.X, for example with #v1.3.5.

Local Development

Building LiveKit plugins locally

For local development, initialize the git submodule containing the Rust code for the LiveKit plugin libraries.

There is a helper script to build the libraries locally and exchange the downloaded libraries with the local build artifacts in the correct Runtime/Plugins folder.

Currently, the build script supports the following arguments:

• macos

• android

• ios

In the following options:

• debug (default)

• release

So a build command is for example:

./Scripts~/build_ffi_locally.sh macos release

VSCode setup

Look at the Unity-SDK.code-workspace setup for VSCode. This will use the Meet Sample as the Unity project and the Unity SDK package as two roots in a multi-root workspace and the Meet.sln as the dotnet.defaultSolution, enabling Rust and C# IDE support.

Debugging

For C# debugging, there is a simple attach launch option called C# Unity, for example in the Meet/.vscode/launch.json.

For Rust / C++ debugging on MacOS, you need to install the CodeLLDB extension. The debug attach is defined in .vscode/launch.json.

1. Build the livekit-ffi lib locally in debug mode with ./Scripts~/build_ffi_locally.sh macos debug

2. Start the Unity Editor

3. Attach to the Unity Editor process (either auto or manual process picker)

4. Start the Scene in Editor

iOS

Add dependent frameworks to your Unity project

select Unity-iPhone -> TARGETS -> UnityFramework -> General -> Frameworks and Libraries -> +

add the following frameworks:

OpenGLES.framework MetalKit.framework GLKit.framework MetalKit.framework VideoToolBox.framework Network.framework

add other linker flags to UnityFramework:

-ObjC

Since libiPhone-lib.a has built-in old versions of celt and libvpx (This will cause the opus and vp8/vp9 codecs to not be called correctly and cause a crash.), you need to ensure that liblivekit_ffi.a is linked before libiPhone-lib.a.

The package now applies an iOS post-build fix that rewrites the exported Xcode project so libiPhone-lib.a is moved after liblivekit_ffi.a in UnityFramework -> Frameworks and Libraries.

It also strips the old CELT object cluster from the exported Libraries/libiPhone-lib.a so Xcode cannot resolve those codec symbols from Unity's archive.

If your project disables package editor scripts or uses a custom Xcode export pipeline that overwrites project.pbxproj after LiveKit runs, you may still need to adjust the order manually by removing and re-adding libiPhone-lib.a.

Examples

Use the samples of the package to see how to use the SDK.

Tokens

You need a token to join a LiveKit room as a participant. Read more about tokens here: https://docs.livekit.io/frontends/reference/tokens-grants/

To help getting started with tokens, use TokenSource.cs with a TokenSourceConfig ScriptableObject (see https://docs.livekit.io/frontends/build/authentication/#tokensource). Create a config asset via Right Click > Create > LiveKit > Token Source Config and select one of three token source types:

1. Literal

Use this to pass a pregenerated server URL and token. Generate tokens via the LiveKit CLI or from your LiveKit Cloud project's API key page.

2. Sandbox

For development and testing. Follow the sandbox token server guide to enable your project's sandbox and get the sandbox ID. Optional connection fields (room name, participant name, agent name, etc.) can be configured in the inspector — leave blank for server defaults.

3. Endpoint

For production. Point to your own token endpoint URL and add any required authentication headers. Uses the same connection options as Sandbox. See the endpoint token generation guide.

Usage

Add a TokenSource component to a GameObject, assign your TokenSourceConfig asset, then fetch connection details before connecting:

var connectionDetailsTask = _tokenSource.FetchConnectionDetails();
yield return new WaitUntil(() => connectionDetailsTask.IsCompleted);

if (connectionDetailsTask.IsFaulted)
{
    Debug.LogError($"Failed to fetch connection details: {connectionDetailsTask.Exception?.InnerException?.Message}");
    yield break;
}

var details = connectionDetailsTask.Result;
_room = new Room();
var connect = _room.Connect(details.ServerUrl, details.ParticipantToken, new RoomOptions());

Connect to a room

using  LiveKit;



IEnumerator  Start()

{

var  room = new  Room();

room.TrackSubscribed += TrackSubscribed;



var  connect = room.Connect("ws://localhost:7880", "<join-token>");

yield  return  connect;

if (!connect.IsError)

{

Debug.Log("Connected to " + room.Name);

}

}

Publishing microphone

var  localSid = "my-audio-source";

GameObject  audObject = new  GameObject(localSid);

_audioObjects[localSid] = audObject;

var  rtcSource = new  MicrophoneSource(Microphone.devices[0], _audioObjects[localSid]);

var  track = LocalAudioTrack.CreateAudioTrack("my-audio-track", rtcSource, room);



var  options = new  TrackPublishOptions();

options.AudioEncoding = new  AudioEncoding();

options.AudioEncoding.MaxBitrate = 64000;

options.Source = TrackSource.SourceMicrophone;



var  publish = room.LocalParticipant.PublishTrack(track, options);

yield  return  publish;



if (!publish.IsError)

{

Debug.Log("Track published!");

}



rtcSource.Start();

Publishing a texture (e.g Unity Camera)

// publish a WebCamera

//var source = new TextureVideoSource(webCamTexture);



// Publish the entire screen

//var source = new ScreenVideoSource();



// Publishing a Unity Camera

//Camera.main.enabled = true;

//var source = new CameraVideoSource(Camera.main);



var  rt = new  UnityEngine.RenderTexture(1920, 1080, 24, RenderTextureFormat.ARGB32);

rt.Create();

Camera.main.targetTexture = rt;

var  source = new  TextureVideoSource(rt);

var  track = LocalVideoTrack.CreateVideoTrack("my-video-track", source, room);



var  options = new  TrackPublishOptions();

options.VideoCodec = VideoCodec.Vp8;

var  videoCoding = new  VideoEncoding();

videoCoding.MaxBitrate = 512000;

videoCoding.MaxFramerate = frameRate;

options.VideoEncoding = videoCoding;

options.Simulcast = true;

options.Source = TrackSource.SourceCamera;



var  publish = room.LocalParticipant.PublishTrack(track, options);

yield  return  publish;



if (!publish.IsError)

{

Debug.Log("Track published!");

}



source.Start();

StartCoroutine(source.Update());

Receiving tracks

IEnumerator  Start()

{

var  room = new  Room();

room.TrackSubscribed += TrackSubscribed;



var  connect = room.Connect("ws://localhost:7880", "<join-token>");

yield  return  connect;



// ....

}



void  TrackSubscribed(IRemoteTrack  track, RemoteTrackPublication  publication, RemoteParticipant  participant)

{

if (track  is  RemoteVideoTrack  videoTrack)

{

var  rawImage = GetComponent<RawImage>();

var  stream = new  VideoStream(videoTrack);

stream.TextureReceived += (tex) =>

{

rawImage.texture = tex;

};

StartCoroutine(stream.Update());

// The video data is displayed on the rawImage

}

else  if (track  is  RemoteAudioTrack  audioTrack)

{

GameObject  audObject = new  GameObject(audioTrack.Sid);

var  source = audObject.AddComponent<AudioSource>();

var  stream = new  AudioStream(audioTrack, source);

// Audio is being played on the source ..

}

}

RPC

Perform your own predefined method calls from one participant to another.

This feature is especially powerful when used with Agents, for instance to forward LLM function calls to your client application.

The following is a brief overview but more detail is available in the documentation.

Registering an RPC method

The participant who implements the method and will receive its calls must first register support. Your method handler will be an async callback that receives an RpcInvocationData object:

// Define your method handler

async  Task<string> HandleGreeting(RpcInvocationData  data)

{

Debug.Log($"Received greeting from {data.CallerIdentity}: {data.Payload}");

return  $"Hello, {data.CallerIdentity}!";

}



// Register the method after connection to the room

room.LocalParticipant.RegisterRpcMethod("greet", HandleGreeting);

In addition to the payload, RpcInvocationData also contains responseTimeout, which informs you the maximum time available to return a response. If you are unable to respond in time, the call will result in an error on the caller's side.

Performing an RPC request

The caller may initiate an RPC call using coroutines:

IEnumerator  PerformRpcCoroutine()

{

var  rpcCall = room.LocalParticipant.PerformRpc(new  PerformRpcParams

{

DestinationIdentity = "recipient-identity",

Method = "greet",

Payload = "Hello from RPC!"

});



yield  return  rpcCall;



if (rpcCall.IsError)

{

Debug.Log($"RPC call failed: {rpcCall.Error}");

}

else

{

Debug.Log($"RPC response: {rpcCall.Payload}");

}

}



// Start the coroutine from another MonoBehaviour method

StartCoroutine(PerformRpcCoroutine());

You may find it useful to adjust the ResponseTimeout parameter, which indicates the amount of time you will wait for a response. We recommend keeping this value as low as possible while still satisfying the constraints of your application.

Errors

LiveKit is a dynamic realtime environment and RPC calls can fail for various reasons.

You may throw errors of the type RpcError with a string message in an RPC method handler and they will be received on the caller's side with the message intact. Other errors will not be transmitted and will instead arrive to the caller as 1500 ("Application Error"). Other built-in errors are detailed in the docs.

Sending text

Use text streams to send any amount of text between participants.

Sending text all at once

IEnumerator  PerformSendText()

{

var  text = "Lorem ipsum dolor sit amet...";

var  sendTextCall = room.LocalParticipant.SendText(text, "some-topic");

yield  return  sendTextCall;



Debug.Log($"Sent text with stream ID {sendTextCall.Info.Id}");

}

Streaming text incrementally

IEnumerator  PerformStreamText()

{

var  streamTextCall = room.LocalParticipant.StreamText("my-topic");

yield  return  streamTextCall;



var  writer = streamTextCall.Writer;

Debug.Log($"Opened text stream with ID: {writer.Info.Id}");



// In a real app, you would generate this text asynchronously / incrementally as well

var  textChunks = new[] { "Lorem ", "ipsum ", "dolor ", "sit ", "amet..." };

foreach (var  chunk  in  textChunks)

{

yield  return  writer.Write(chunk);

}



// The stream must be explicitly closed when done

yield  return  writer.Close();



Debug.Log($"Closed text stream with ID: {writer.Info.Id}");

}

Handling incoming streams

IEnumerator  HandleTextStream(TextStreamReader  reader, string  participantIdentity)

{

var  info = reader.Info;

Debug.Log($@"

Text stream received from {participantIdentity}

Topic: {info.Topic}

Timestamp: {info.Timestamp}

ID: {info.Id}

Size: {info.TotalLength} (only available if the stream was sent with `SendText`)

");



// Option 1: Process the stream incrementally

var  readIncremental = reader.ReadIncremental();

while (true)

{

readIncremental.Reset();

yield  return  readIncremental;

if (readIncremental.IsEos) break;

Debug.Log($"Next chunk: {readIncremental.Text}");

}



// Option 2: Get the entire text after the stream completes

var  readAllCall = reader.ReadAll();

yield  return  readAllCall;

Debug.Log($"Received text: {readAllCall.Text}")

}



// Register the topic before connecting to the room

room.RegisterTextStreamHandler("my-topic", (reader, identity) =>

StartCoroutine(HandleTextStream(reader, identity))

);

Sending files & bytes

Use byte streams to send files, images, or any other kind of data between participants.

Sending files

IEnumerator  PerformSendFile()

{

var  filePath = "path/to/file.jpg";

var  sendFileCall = room.LocalParticipant.SendFile(filePath, "some-topic");

yield  return  sendFileCall;



Debug.Log($"Sent file with stream ID: {sendFileCall.Info.Id}");

}

Streaming bytes

IEnumerator  PerformStreamBytes()

{

var  streamBytesCall = room.LocalParticipant.StreamBytes("my-topic");

yield  return  streamBytesCall;



var  writer = streamBytesCall.Writer;

Debug.Log($"Opened byte stream with ID: {writer.Info.Id}");



// Example sending arbitrary binary data

// For sending files, use `SendFile` instead

var  dataChunks = new[] {

new  byte[] { 0x00, 0x01 },

new  byte[] { 0x03, 0x04 }

};

foreach (var  chunk  in  dataChunks)

{

yield  return  writer.Write(chunk);

}



// The stream must be explicitly closed when done

yield  return  writer.Close();



Debug.Log($"Closed byte stream with ID: {writer.Info.Id}");

}

Handling incoming streams

IEnumerator  HandleByteStream(ByteStreamReader  reader, string  participantIdentity)

{

var  info = reader.Info;



// Option 1: Process the stream incrementally

var  readIncremental = reader.ReadIncremental();

while (true)

{

readIncremental.Reset();

yield  return  readIncremental;

if (readIncremental.IsEos) break;

Debug.Log($"Next chunk: {readIncremental.Bytes}");

}



// Option 2: Get the entire file after the stream completes

var  readAllCall = reader.ReadAll();

yield  return  readAllCall;

var  data = readAllCall.Bytes;



// Option 3: Write the stream to a local file on disk as it arrives

var  writeToFileCall = reader.WriteToFile();

yield  return  writeToFileCall;

var  path = writeToFileCall.FilePath;

Debug.Log($"Wrote to file: {path}");



Debug.Log($@"

Byte stream received from {participantIdentity}

Topic: {info.Topic}

Timestamp: {info.Timestamp}

ID: {info.Id}

Size: {info.TotalLength} (only available if the stream was sent with `SendFile`)

");

}



// Register the topic after connection to the room

room.RegisterByteStreamHandler("my-topic", (reader, identity) =>

StartCoroutine(HandleByteStream(reader, identity))

);

Verbose Logging

To enable verbose logging, define the LK_VERBOSE symbol:

1. Navigate to Project Settings → Player

2. Select your platform tab (e.g., Mac, iOS, Android).

3. Under Other Settings → Scripting Define Symbols, add LK_VERBOSE.

LiveKit Ecosystem
Agents SDKs	Python · Node.js
LiveKit SDKs	Browser · Swift · Android · Flutter · React Native · Rust · Node.js · Python · Unity · Unity (WebGL) · ESP32 · C++
Starter Apps	Python Agent · TypeScript Agent · React App · SwiftUI App · Android App · Flutter App · React Native App · Web Embed
UI Components	React · Android Compose · SwiftUI · Flutter
Server APIs	Node.js · Golang · Ruby · Java/Kotlin · Python · Rust · PHP (community) · .NET (community)
Resources	Docs · Docs MCP Server · CLI · LiveKit Cloud
LiveKit Server OSS	LiveKit server · Egress · Ingress · SIP
Community	Developer Community · Slack · X · YouTube
