Dynamic Dungeon

Dynamic Dungeon is a powerful node-based procedural tilemap generation tool for Unity. It allows for the creation of complex, constrained, and organic environments by leveraging a semantic approach to world-building.

---

Quick Navigation

• Data Types Legend
• Detailed Tool Documentation
• Tutorials
• Developer Guide
• Glossary of Terms
• Example Projects
• Noise Nodes
• Filter & Transform Nodes
• Maths & Composite Nodes
• Biome Nodes
• Spatial Query & Points
• Growth & Organic Nodes
• Placement Nodes
• Output & World Writing
• Common Workflows

---

Data Types Legend

Understanding the data types flowing between ports is essential for building valid graphs.

Type	Visual Cue	Description
Float	Grey Port	Decimal values (typically 0.0 to 1.0). Used for noise, weight maps, and gradients.
Int	Blue Port	Whole numbers. Used for Logical IDs, Biome indices, and discrete categories.
Bool Mask	Gold Port	Binary 'True' or 'False' states. Used for region masking and logic gates.
Point List	Pink Port	A collection of discrete (X, Y) coordinates for object placement.
Placements	Green Port	Advanced records including asset references, rotation, and mirroring.

---

Detailed Tool Documentation

For in-depth guides on the two primary systems in Dynamic Dungeon, please refer to the following documents:

• Constraint Generator: High-level layout engine for rooms, corridors, and connectivity.
• World Generator: Low-level node-based graph tool for tilemaps and prefab placement.
• Map Diagnostics: Analysis tools for pathfinding, reachability, and walkability validation.
• Glossary of Terms: Definitions for all core procedural generation and semantic concepts.

---

Tutorials

Follow these step-by-step guides to get started with Dynamic Dungeon:

1. Creating Your First World (Procedural Caves)
2. Creating Your First Dungeon
3. Combining World and Dungeon (The Bridge)
4. Validating Your World with Diagnostics

---

Developer Guide

If you are looking to extend Dynamic Dungeon with custom nodes, constraints, or code-driven generation, please refer to our technical guide:

• Developer Guide: technical overview of the node API, Job System integration, and solver extension.

---

Example Projects

A collection of pre-built scenes and graphs demonstrating the tool's capabilities:

• Example Projects Guide: Overview of the Dungeon, Organic Cave, Organic Islands, and Terraria demos.

---

Node Reference

This comprehensive reference documents all available nodes in the Dynamic Dungeon toolset, categorised by their functional role. Each entry outlines the required port connections and provides a summary of the node's procedural logic.

---

Noise Nodes

Generators that produce continuous float data as the foundation for terrain and organic features.

Node	Inputs	Outputs	Summary
PerlinNoise	(none)	Float	Standard smooth pseudo-random noise. Best for natural terrain and weight maps.
SimplexNoise	(none)	Float	Similar to Perlin but with fewer directional artefacts. More computationally efficient.
VoronoiNoise	(none)	Float	Cellular noise. Produces distinct regions and angular boundaries (cracked earth).
FractalNoise	(none)	Float	Layered noise (Octaves). High detail, useful for multi-scale erosion effects.
WhiteNoise	(none)	Float	Purely random per-tile values. Used for grain, dithering, or point seeding.
GradientNoise	(none)	Float	Deterministic spatial gradients (Linear X/Y, Radial, Diagonal).
SurfaceNoiseNode	(none)	Float	Generates a 1D noise-driven horizontal surface, outputting 1.0 below the line.
ConstantNode	(none)	Float, Int	Emits a single constant value across the entire channel.

---

Filter & Transform Nodes

Nodes that modify existing channels to refine shapes or extract specific features.

Node	Inputs	Outputs	Summary
ThresholdNode	Float	Bool Mask	Converts float values to a binary mask based on a cutoff value.
InvertNode	Float / Bool	Match Input	Flips values (1 - value for float, NOT for bool).
ClampNode	Float	Float	Restricts values to a specified min/max range.
RemapNode	Float	Float	Linear remapping from one range (e.g., 0-1) to another (e.g., -50 to 50).
NormaliseNode	Float	Float	Normalises a channel to 0–1 based on the actual min/max found in the data.
StepNode	Float	Float	Quantises values into N discrete steps (posterisation).
SmoothstepNode	Float	Float	S-curve interpolation between two edges for soft transitions.
EdgeDetectNode	Float / Int	Bool Mask	Detects boundaries where neighbouring tiles have different values.
DistanceFieldNode	Bool Mask	Float	Computes distance to the nearest 'true' tile in a bool mask.
CellularAutomata	Bool Mask	Bool Mask	Iterative smoothing using B/S rules (e.g., B3/S45678 for organic caves).
AxisBandNode	(none)	Float	Generates a horizontal or vertical band at a fixed coordinate range.
HeightBandNode	(none)	Float	Specialised Axis Band for vertical height with support for anchoring to world top/bottom.
HeightGradient	(none)	Float	Simple vertical 0-1 gradient covering the full world height.
ColumnSurfaceBand	(none)	Float	Specialised Axis Band for surface-relative features in column-based maps.

---

Maths & Composite Nodes

Perform arithmetic or blend multiple channels together.

Node	Inputs	Outputs	Summary
AddNode	Float (x2)	Float	Adds two channels. Used for layering heightmaps (e.g., Base + Detail).
MultiplyNode	Float (x2)	Float	Multiplies two channels. Essential for masking one noise with another.
BlendNode	Float (x2), Mask	Float	Linear interpolation (Lerp) between two inputs based on a weight/mask.
MaxNode	Float (x2)	Float	Returns the higher value. Useful for combining non-overlapping peaks.
Composite	Float (×N)	Float	Multi-input stack with individual weights and blending modes.
SelectNode	Float (×N)	Float	Multi-way selection based on a control float channel's range.
CombineMasks	Bool (x2)	Bool Mask	Logical operations between masks: AND, OR, XOR, NOT.
MaskStackNode	Bool (×N)	Bool Mask	Procedural list of mask operations (Add/Subtract/Intersect) applied in order.
MaskExpression	Bool (×N)	Bool Mask	Complex boolean logic evaluator for combining multiple inputs.

---

Biome Nodes

System-level nodes for assigning environmental assets to regions.

Node	Inputs	Outputs	Summary
BiomeLayerNode	Float (opt)	Biome	Assigns biomes along an axis or driven by a data channel.
BiomeOverride	Biome, Mask	Biome	Overwrites tiles in a mask with a specific biome. Supports soft blending.
BiomeSelector	Float/ Int	Biome	Advanced assignment using Range (1D), Matrix (2D), or Cell (Lookup) modes.
BiomeLayout	(none)	Biome	Constraint-based biome solver (Voronoi/Relaxed) for macroscopic layout.
BiomeMerge	Biome (×N)	Biome	Combines multiple biome channels into a single priority-resolved channel.
BiomeMaskNode	Biome	Bool Mask	Extracts a mask where a specific BiomeAsset is present.
BiomeWeightBlend	Biome (x2), Weight	Biome	Blends between two biomes using a weight map. Supports transitional textures.

---

Spatial Query & Points

Analyse the world or generate discrete positions for object placement.

Node	Inputs	Outputs	Summary
ContextualQuery	(reads world)	Point List	Finds positions matching a neighbourhood pattern (Logical ID/Semantic Tag).
Neighbourhood	(reads world)	Bool Mask	Checks if a specific ID/Tag exists within a radius (Chebyshev/Euclidean).
PoissonSampler	Bool/ Float	Point List	Generates randomly distributed points with a minimum separation.
StochasticScatter	Float	Point List	Probabilistic per-tile scatter based on noise/mask weight.
PointGridNode	(none)	Point List	Regular grid of points with optional jitter.
EdgeFinderNode	(reads world)	Point List	Generates points along the boundaries between different Logical IDs.
PointOffset	Point List	Point List	Shifts every point in a list by a fixed or noise-driven vector.
PointToMask	Point List	Bool Mask	Converts a list of points into a binary mask (1.0 at point location).

---

Growth & Organic Nodes

Simulate natural expansion or directional carving.

Node	Inputs	Outputs	Summary
ClusterNode	Point/ Mask	Bool Mask	Grows probabilistic blobs from seed points. Spread decreases with distance.
VeinNode	Point/ Mask	Bool Mask	Directed random walk to create filament-like structures (e.g., rivers, ores).
PerlinWormNode	Bool Mask (opt)	Bool Mask	Smooth, noise-steered carving. Ideal for tunnels or vertical surface shafts.

---

Placement Nodes

Nodes that generate or stamp prefab data onto the world grid.

Node	Inputs	Outputs	Summary
DungeonGenerator	Point List	Int, Placements	High-Level Solver. Generates complex constraint-based dungeons at input points.
PrefabStamperNode	Point List or Bool Mask	(writes world)	Places pre-built Unity Tilemap chunks at input positions.
PlacementSetNode	Weights, Masks	Placements	Generates multiple prefab placement rows from one multi-input weight stack.
PrefabSpawnerNode	Point List	Placements	Instantiates Unity Prefabs (GameObjects) at specific points.

---

Output & World Writing

Final nodes that translate abstract data into Unity Tilemap data.

Node	Inputs	Outputs	Summary
TilemapOutput	Int, Biome, Placements	(terminal)	Terminal Node. Receives the final Logical ID channel for generation.
MaskToLogicalId	Bool Mask	Int	Assigns two specific Logical IDs based on a mask (e.g., Wall vs Floor).
LogicalIdOverlay	Int, Bool Mask	Int	Overwrites a base ID channel with a specific ID where the mask is true.
LogicalIdRuleStack	Int, Mask (×N)	Int	Sequential list of ID overwrite rules based on procedural masks.
FlatFillNode	(none)	Int	Fills the entire world with a single constant Logical ID.
EmptyGridNode	(none)	Match Input	Resets a channel to its default empty state (e.g., 0.0 or Void).

---

Common Workflows

Combine these nodes to achieve standard procedural effects.

• Organic Caves: Perlin Noise → Threshold → Cellular Automata → Tilemap Output.
• Vertical Biomes: Height Gradient → Biome Selector → Tilemap Output.
• Vegetation Scatter: Voronoi Noise → Stochastic Scatter → Placement Set → Tilemap Output.
• Dungeon Tunnels: Perlin Worm → Logical ID Overlay → Contextual Query → Prefab Spawner.
• Full Dungeon: Poisson Sampler → Dungeon Generator → Tilemap Output.
